120KW SOLAX X3 FORTH 3PH GRID TIE INVERTER

SOLAX 120KW X3 FORTH 3PH GRID TIE INVERTER

The SOLAX 120KW X3 FORTH 3PH Grid Tie Inverter is a high-capacity commercial and industrial (C&I) on-grid inverter engineered to deliver powerful performance, exceptional efficiency, and intelligent system management. Designed for large-scale solar installations such as factories, warehouses, shopping centres, and industrial facilities, this advanced SOLAX inverter ensures maximum energy production and long-term reliability.

With cutting-edge technology and flexible system integration, the SOLAX X3 FORTH 120KW inverter allows businesses to optimize solar energy generation while maintaining safe and efficient operation.

High Efficiency Performance

The SOLAX inverter is designed to maximize energy conversion and system productivity.

• Up to 99% efficiency for optimal solar energy conversion

• Wide 180V – 1000V MPPT voltage range for flexible system design

• Supports 150% PV oversizing to increase solar generation capacity

• 110% AC output overloading capability

• 12 MPPT trackers with 2 strings per MPPT for enhanced energy harvesting

• 32A maximum input current per MPPT

• Maximum recommended PV array power: 180kWp

Advanced Safety Protection

The SOLAX X3 FORTH 120KW is equipped with comprehensive protection features to ensure safe and reliable operation in demanding environments.

• IP66 protection rating for outdoor and harsh weather conditions

• Type II SPD surge protection on both AC and DC sides

• AC terminal temperature detection for improved safety

• String current monitoring for system diagnostics

• Optional AFCI support for arc fault protection

• 24-hour operation monitoring for continuous system performance tracking

Intelligent System Design

Smart technology built into the SOLAX inverter enhances monitoring and system management.

• Night-time reactive power compensation

• I-V curve diagnosis for advanced system analysis

• Remote configuration and firmware upgrades

• Smart air cooling system to extend fan lifespan

• Advanced heat dissipation design reducing system size and weight by over 5%

Flexible Installation & Connectivity

The SOLAX 120KW inverter is designed for large commercial solar systems with flexible installation options.

• Built-in export power control function

• Aluminium AC cable connection available

• Maximum PV input voltage: 1100V

• Start-up voltage: 200V

• 12 MPPTs with 2 strings per MPPT for maximum system flexibility
